LX-3D MKII 4" Atmos/Surround Speakers (Pair)

LX-3D MKII 4" Atmos/Surround Speakers (Pair)

Regular price $469.99
Regular price Sale price $469.99
Sale Sold out
Color

LX-3D MKII is a 2-way Centre speaker with a 4″ bass driver and a 1″ softdome treble unit.

The LX MKII Series is the latest in a long line of distinguished Mission loudspeakers, joining the multi-award winning speakers from the mid-level QX Series and the flagship ZX Series. LX MKII maintains the Mission trademark ‘Inverted Driver Geometry’ design, which means the path length between the drivers is optimised. Unique at this price-point, this arrangement allows the precision-tuned crossover to yield improved transient attack and astonishing detail.

Perfected over hundreds of hours of critical listening by Mission’s lead acoustic designer, Peter Comeau, Mission LX MKII utilises trickle-down innovations from the revered ZX series. Improvements in the famous Mission DiaDrive bass unit offer superior control of the low-frequency diaphragm while a refined high-frequency performance and a re-engineered cabinet bracing system further help create a loudspeaker system that outperforms its price-class.

View full details

Collapsible content

LX-3D MKII Specifications

General description 2-way bookshelf speaker Bass extension(-6dB) 90Hz
Enclosure type closed-box system Crossover frequency 2.8kHz
Transducer complement 2-way Cabinet Volume (in litres) 2.2L
Bass driver 4"(100mm) composite fibre Height (on plinth) 180mm
Width 160mm
Treble driver 25mm microfibre dome Depth (with terminals) 260mm
AV shield No Carton size 365 x 345 x 245mm
Sensitivity (2.83V @ 1m) 86dB Net weight 2.85kg/pcs
Recommended amplifier power 20-80W Gross weight 6.2kg/ctn
Peak SPL 99dB Finish Walnut Pearl / Lux White / Lux Black
Nominal impedance 8Ω Compatible
Minimum impedance 4.5Ω
Frequency response (+/-3dB) 105Hz ~ 20kHz

Continuous Innovation

From over 40 years of British Hi-Fi heritage and experience, LX MKII is a representation of Mission’s non-stop pursuit of improvement and excellence

Advanced New Driver Surrounds and Crossover

One of the critical areas highlighted by the development of Mission ZX and QX models was the use of serrations in the driver surrounds to help scatter interfering reflections from localised surfaces to the dome and cone

LX MKII now incorporates these serrations into the driver surrounds, adding further finesse to the drive unit outputs and providing a smoother frequency response

With minor perturbations in the driver response ironed out, the crossover for each model has been optimised to take advantage of the improved performance

The result is that the LX MKII builds on the winning formula of the LX, both enhancing the clarity of
midrange and treble detail and improving the micro-dynamics of the musical performance for an even more thrilling listener experience

Inverted Geometry Drive Design

Mission’s classic IDG (Inverted Driver Geometry) driver format positions the high frequency below the bass / midrange driver meaning the length of path is equalised so the sound waves coincide at the listener’s head height. A proprietary principle that improves ‘time alignment’ and thus transient performance in Mission speakers

A New Start, With a New Finish

Standout new finish options follow the Mission mantra of fusing Hi-Fi heritage with contemporary design. LX MKII is beautifully finished in a choice of walnut pearl, and the latest Lux Black matte finishes.

LX MKII is the epitome of affordable high-end audio, harnessing materials, techniques and technologies that you would only expect to find in other speakers costing many times the price

Whatever your choice of music, LX MKII will reproduce it with outstanding accuracy, detailing and realism, embodying Mission’s traditional adage since the 1970s
